BRAND DISTINCTION: ENGINEERED WITH WALTER'S SPECIALIZED TIGER·TEC® GOLD MATERIAL COATED SURFACES TO EXTEND OPERATION LIFE ON HIGH-SPEED CNC MILLING MILLS Walter Tools.
SHAPE GEOMETRY: UTILIZES A GEOMETRIC R-HAND RHOMBIC PARALLELOGRAM CONTOUR PERMITTING SMOOTH ACCURATE 90-DEGREE SQUARE-SHOULDER MILLING PASSES.
CLEARANCE CAPABILITY: “Clearance angle major. α 15 ° Minor clearance angle. α2. 20 °” prevents flank face friction against deep workpiece pockets Camcut Group.
RAKE PROFILE: “The tool System inserts, positive with two cutting edges; Circumference-sintered (ADMT…) F56 – The universal one; 16° rake angle.” ToolsUnited.
TOLERANCE CODE: HELD TO SECURE METRIC INDUSTRIAL CLASS STANDARDS PROTECTING AGAINST RUNOUT SPINDLE ERROR VIBRATIONS ACROSS SWAPPED EDGES.
FIXING GEOMETRIC: INTEGRATES A REINFORCED CENTER TAPERED FIXING HOLE ACCOMMODATING HIGH-TORQUE COUNTERSUNK INTERNAL SCREW RETENTION SLEEVES.
EDGE MEASUREMENT: THE 12 BLOCK SEGMENT INDICATES AN INSCRIBED CUTTING BOUNDARY DESIGN COMPATIBLE WITH EXTENSIVE LONGITUDINAL SHOULDER SWEEPS.
BODY THICKNESS: “ADMT120420R-F56 WSM35G. Radius. R. 2 mm. Insert thickness. s. 4,76 mm.” engineered to absorb harsh structural mechanical shock loads Camcut Group.
WIPER GEOMETRY: “Wiper cutting edge length. b. 1 mm. Number of cutting edges. 2.” built-in to sweep away marks and achieve smooth floor finishes Camcut Group.
SUBSTRATE TECHNOLOGY: UTILIZES A PARTICULATE-GRADIENT HIGH-COBALT CARBIDE MATRIX PROFFERING AN OUTSTANDING RATIO OF STRUCTURAL FRACTURE TOUGHNESS.
THERMAL CAPACITY: EXTRAORDINARY THERMAL SHOCK IMMUNITY ALLOWS SUCCESSFUL HIGH-SPEED PERFORMANCE DURING BOTH WET COOLANT RUNS AND DRY MACHINING.
CHIPPING RESISTANCE: THE GOLD TITANIUM NITRIDE BASE COATING HELPS MACHINE OPERATORS QUICKLY SEE Edge WEAR COMPARED TO DARK METALS.
TARGET METALS: OPTIMIZED AS A PRIMORDIAL CHOICE FOR STAINLESS STEELS (ISO M), HEAT-RESISTANT SUPERALLOYS (ISO S), AND TOUGH TENSILE CARBON ALLOYS.
MACHINING RANGE: “F56 – The universal one. For medium machining conditions. Can be used universally for most materials.” Walter Tools.
EDGE ECONOMY: CONFIGURABLE SYSTEM FEATURING DUAL HIGH-SHEAR ROTATABLE CUTTING FLUTES LOWERING RE-TOOLING INVENTORY DEPRECIATIONS.
