BRAND REPUTATION: ENGINEERED BY KYOCERA TO DELIVER CONSISTENT RED-HARDNESS PROTECTION AND EXCELLENT DIMENSIONAL MACHINE ACCURACY OVER LONG WORKPIECE RUNTIMES.
SHAPE GEOMETRY: “EPSR (GTC - Insert included angle): 55 Degree.” as certified by the Hoffmann Group, allowing great clearance paths for profiling narrow step shoulders.
CLEARANCE ANGLE: “AN (GTC - Clearance angle major): 7 Degree.” provides a standard positive relief slope to drastically limit rubbing and back-face component friction Hoffmann Group.
TOLERANCE FORMAT: “TC (GTC - Tolerance class insert): M.” keeps structural indexing runout restricted to ensure high-precision replacement transitions across production turrets Hoffmann Group.
FIXING GEOMETRIC: CONFIGURED WITH A SINGLE-SIDED G-TYPE HOLLOW CYLINDRICAL RETENTION CORE HOLE MATED TO SYMMETRICAL RECESSED CHIPBREAKER RAMPS.
EDGE MEASUREMENT: MARKED WITH THE 11 DIMENSIONAL CONTEXT TRANSLATING TO A PRECISE INSCRIBED CIRCLE (IC) NOMINAL SIZE STANDARD OF 9.525 MM.
BODY THICKNESS: “S (GTC - Insert thickness): 3.97 mm.” prevents sudden structural fractures when experiencing variable mechanical cutting loads Hoffmann Group.
NOSE RADIUS: “RE (GTC - Corner radius): 0.4 mm.” provides an ideal edge balance for sharp precision corner definitions and fine-to-medium component profiling Hoffmann Group.
COATING SPECIFICATION: “H5, Coating, MEGACOAT NANO PLUS ;” maximizes surface wear capabilities by using multi-laminated nano-scale crystalline material boundaries ToolsUnited.
SURFACE POLISH SMOOTHNESS: HIGHLY SLICK LUBRICATED COATING BOUNDARIES REPEL SHOCK FRICTION, SIGNIFICANTLY PREVENTING THE INITIAL FORMATION OF CHIP SLAG WELDING (BUE).
CHIPPING SUPPRESSION: REINFORCED STRESS-OPTIMIZED INTERNAL NANO LAYERS PREVENT MICRO-CHIPPING CORROSION ENCOUNTERED ALONG CRITICAL PROFILE TURNING LINES.
PRIMARY APPLICATION TARGET: “PR1725 : 1st Recommendation for steel machining.” but delivers stable, multi-material reliability during high-speed setups KYOCERA Precision Tools.
STAINLESS EXTENSION CAPACITY: “PR1725 shows less damage on the cutting edge and maintains stable finish results on the workpiece surface.” when cutting demanding SUS304 alloys Syndigo.
MACHINING RANGE BOUNDARIES: OPTIMIZED EXCLUSIVELY FOR EXECUTING CONTINUOUS HIGH-SPEED SEMI-FINISHING RUNS, NARROW SLOTS, INTERNAL BORING, AND UNINTERRUPTED PROFILE STEPS.
TOTAL OPERATING LIFE: THE HIGH LUBRICITY EXPANDS TOTAL PER-EDGE COMPONENT OUTPUT YIELDS AND DELIVERS OUTSTANDING WORKPIECE SURFACE SHINE MARKS.
