  • SN1206-45-160-40-11T
  • SN1206-45-160-40-11T
SN1206-45-160-40-11T

SN1206-45-160-40-11T

Brand: TOOLFARM

The code SN1206-45-160-40-11 (also widely classified as SNMX1206-160-40-11T-45°) identifies a massive, industrial-grade indexable face milling cutter body.  It is engineered exclusively for heavy-duty metal removal, flat-facing large metal blocks, and roughing operations on robust CNC vertical or horizontal machining centers.

₹14000.00

₹14000.00

Share on:
product details

SN1206: Specifies the precision pocket architecture designed to load square SNMX 1206 or SNEX 1206 double-sided indexable inserts.

www.kovonastrojecz.com
45: Denotes a 45-degree approach/lead angle. This angle helps in chip thinning, which spreads out the structural load and directs massive cutting forces axially up into the spindle, significantly reducing radial vibration.
160: Represents the extensive outer cutting diameter  of 160 mm (approx. 6.3 inches) for rapid surface coverage.
40: Indicates a 40 mm inner bore pilot hole. The cutter disk directly bolts onto a standard FMB40 heavy face mill arbor.

www.kovonastrojecz.com
11: Denotes 11 Teeth (Flutes / Pockets) distributed around the body. This close-pitch configuration balances high table feed rates with excellent cutting stability
