SRGCL 2020K06

SRGCL 2020K06

Brand: TOOLFARM

The SRGCL 2020K06 is a left-hand external turning toolholder designed for CNC lathe and metal machining operations.

₹1800.00

₹1800.00

Share on:
product details
  • S: Screw-down clamping system for maximum clearance and secure insert holding.
  • R: Round insert shape, providing strong cutting edges ideal for profiling operations.
  • G: Side cutting edge angle built specifically for face, contour, or longitudinal turning.
  • C: 7-degree insert clearance angle, which prevents tool rubbing against the workpiece.
  • L: Left-hand cutting direction (moves from left to right toward the tailstock, or requires reverse spindle rotation).
  • 2020: Shank size measuring exactly 20mm in height by 20mm in width.
  • K: Total tool length of 125mm.
    • 06: Insert size designation, made for round inserts with a 6mm cutting edge diameter (Inscribed Circle).
