Brand Reputation: “Kyocera products are widely acknowledged in the market for their high quality.” providing maximum process security on automated lines.
Shape Geometry: Employs a slim V-style 35-degree diamond silhouette to clear restricted undercuts and steep multi-directional profiling paths.
Clearance Configuration: Formed with a zero-degree negative N-type side clearance profile to give the sharp tip maximum physical backing support.
Tolerance Designation: Strictly adheres to the M-class ISO precision tolerance format to secure highly uniform centerline heights during tool changes.
Fixing Geometry: Features a G-type cylindrical center hole combined with molded double-sided chipbreakers for rigid pin-and-clamp setups.
Edge Sizing: Standardized 16 mm physical cutting edge layout compatible with heavy-duty industrial external and internal boring bars.
Body Thickness: Designated by the 04 structural value, yielding an exact dimensional cross-sectional depth of 4.76 mm.
Nose Radius: Built with an ultra-fine 0.2 mm corner radius (02 code), keeping radial force low to prevent part deflection and chattering.
Core Technology: “Special reinforcing technology (hybrid technology) achieves both superior fracture resistance and wear resistance.” preventing unexpected structural cracking.
Gradient Structure: Features a hard outer micro-grain layer for wear protection transitioning into a high-toughness core for impact absorption.
Operating Performance: “PV720: The foremost recommended PVD cermet for steel machining.” capable of running at high cutting speeds (\(V_{c}\)).
Surface Polish Quality: “Realizes both high-efficiency machining and a high-grade finished surface.” producing a clean, mirror-like part shine.
Adhesion Defense: Highly stable bonding layers eliminate chemical affinity with steel chips, preventing built-up edge (BUE) formation.
Wear Milestones: Provides up to a 50% increase in continuous wear resistance compared to traditional non-hybrid cermet variations.
Edge Inspection: The outer gold-colored TiN coating layer offers excellent visibility, allowing operators to spot edge wear even in dim lighting.
