BRAND METRICS: CREATED VIA KYOCERA’S COMPREHENSIVE ADVANCED CERAMIC RESEARCH TO SECURE SUPERIOR PROCESS RELIABILITY ON CNC PRODUCTION LINES.
SHAPE PROFILE: UTILIZES A SHARP V-STYLE 35-DEGREE DIAMOND CONFIGURATION THAT ACCESSES RESTRICTED UNDERCUTS AND NARROW STEPPED SHOULDERS.
CLEARANCE ANGLE: BUILT WITH AN N-TYPE ZERO-DEGREE NEGATIVE RELIEF STRUCTURE TO ASSURE EXTREME EDGE STRENGTH ACROSS 4 USABLE CORNERS.
TOLERANCE CLASS: COMPLIES WITH THE M-CLASS INDUSTRIAL DIMENSIONAL CODE TO ENSURE TIGHT INDEXING CENTERLINE HEIGHT DURING REPLACEMENTS.
FIXING GEOMETRIC: INTEGRATES A G-TYPE CYLINDRICAL CENTER CLAMP HOLE MATCHING STANDARD TOP-CLAMP OR PIN-LOCK STYLE TOOL HOLDERS.
EDGE DIMENSION: BUILT WITH A 16 MM EXTERIOR CUTTING EDGE SCALE SUITED FOR STANDARD NEGATIVE-STYLE LATHE TURNING BARS.
BODY THICKNESS: REPRESENTED BY THE 04 SPECIFICATION COMPLYING WITH A UNIFORM CROSS-SECTIONAL DEPTH OF EXACTLY 4.76 MM.
NOSE RADIUS: FORMULATED WITH A 0.4 MM CORNER RADIUS BALANCING CRITICAL SHARP CORNER ACCURACY WITH ADEQUATE TIP STRENGTH.
HYBRID SUBSTRATE: “Special reinforcing technology (hybrid technology) achieves both superior fracture resistance and wear resistance.” preventing sudden structural tool breaking.
GRADIENT STRUCTURE: EMBODIES A HARD MICRO-GRAIN SURFACE STRUCTURE EXPANDING INTO A SHOCK-ABSORBING CORE MATERIAL LAYER.
GRADE PROFILE: “PV720: The foremost recommended PVD cermet for steel machining.” optimized for highly predictable automation cycles.
SURFACE POLISH: “Realizes both high-efficiency machining and a high-grade finished surface.” eliminating secondary component polishing steps.
ANTI-WELDING FOCUS: METALLURGICALLY DESIGNED TO RESIST CHEMICAL AFFINITY WITH HIGH-TEMPERATURE STEEL CHIPS TO ELIMINATE BUILT-UP EDGE (BUE).
TARGET MATERIALS: EXCLUSIVELY TUNED FOR STABLE HIGH-SPEED CONTINUOUS RUNNING ACROSS CARBON, ALLOY, AND PRE-HARDENED FORGED STEELS.
WEAR MILESTONES: DELIVERS A MASSIVE LEAP IN CRATER AND BOUNDARY FLANK WEAR PROTECTION COMPARED TO NON-HYBRID TRADITIONAL CERMETS.
